Project
INVESTING IN CREATIVITY
Manipulator Support and
Tool Design for Milling36 Slot
November 2020
Through this project, it has a deeper understanding of the parts processing and manufacturing process, processing technology and fixture design, but also to deepen the basic knowledge of the textbook learning and understanding, especially the mechanical manufacturing engineering principles of the textbook knowledge. Through curriculum design, the theoretical knowledge in textbooks can be better combined with actual production. In the specific design process, from the initial panel discussion and analysis, found that they are many shortcomings, many issues are not considered carefully, design loopholes, processing accuracy can not reach, interference and so on. The design is correct in theory, but there are various problems in the actual processing. Therefore, in the design must fully consider whether the design of the institution is reasonable, in practice can work properly, and not only consider the theoretical feasibility, curriculum design so that it’s learned to process parts and design fixtures from the actual point of view.
Automatic Dum Truck Design
September 2020
Our project is an automation of a dump truck that moves linearly on top of a box. The system around it is designed to drop a marble in the back, which is carried by the truck and deposited at the end of the box on a person. The marble travels down a rut and is deposited on a rising conveyer belt. The belt takes it to a tower positioned over the dump truck (on the opposite end). Sensors on the track of the dump truck tell when it’s below the tower, opening a trap door which deposits the marble in the back for the motion to start again. Other computational additions, which were not completed, include a mechanism for making sound as the truck reverses direction and a mechanism for moving the person (to avoid the marble).
